Laser Ablation Imaging Portfolio

Search Imaging Collection

Search our collection of image mapping from a variety of sample types, applications, elements, and systems. By default, a few images are highlighted below.
For credit details on a specific image, please contact [email protected].

Mouse Brain - A cross sectional image of age related changes of Fe (red), Zn (green) and Cu (blue) in mouse brain using a 10 μm spot, 100 Hz repetition rate. Image area: Area of 5.5 x 4.5 mm. Analysis time of 41 minutes.
System: imageBIO266
Sample Type: Biology
Analyte: Zinc, Copper, Iron
Credit: Northwestern University
